Designed to maximise pillion comfort and create a feeling of unison between rider and passenger, the Crossrunner also addresses the aspect of another strong consideration at initial stage. The engine.
With most sport tourer machines using an in-line four cylinder engine and most adventure motorcycles using a twin cylinder powerplant, the design team had an exciting opportunity. A smooth, flexible and soulful 800cc V4 engine, specifically tuned for a machine that helps a rider find a flowing rhythm.
With the attributes of both a performance machine and an adventure bike, the Crossrunner is a new kind of motorcycle. One that can effortlessly adapt to many different styles of riding.
Honda's exciting new entry into the adventure touring category
The Crossrunner represents the best of two biking genres: the flexibility of a performance machine with an upright riding position as well as the rugged appearance of an adventure bike.
The Crossrunner is powered by a liquid-cooled 782cc, 4 cam, V4 engine with VTEC that delivers a smooth curve of power with excellent torque throughout the rev range.
This provides the rider a precisely controlled experience, be it for short urban trips or for covering vast distances.
Thee rider's level of control is further enhanced by the wider than normal handlebar configuration, responding accurately yet quickly to small steering inputs, whilst its aluminium alloy twin-spar frame provides excellent rigidity.
The Crossrunner has also been designed to maximise pillion comfort. The passenger is seated on a level, low platform to make mounting and dismounting easier whilst maximising wind protection.
The bike's low-slung 4-2-1 exhaust system leaves room for a lower, flatter pillion seat as well as allowing for an attractive exhaust design, excellent cornering clearance and that distinctive V4 engine note.
Crucial machine data is provided by a 'floating' instrument binnacle, placed high for optimum visibility at all times, including a digital LCD speedometer, tachometer, twin trip meters, a coolant temperature gauge, an ambient temperature indicator and a clock.
A 43mm cartridge-type front fork provides supreme front wheel control and excellent rider feedback.
Cast aluminium Pro-Arm swingarm
, Pro-Link rising-rate linkage system and gas-charged HMAS damper with adjustable rebound combine for comfort and precise control.
Braking is of the highest standard and includes high-performing Combined brakes with standard-fit ABS to create powerful, assured braking with optimised control and feedback.
The Crossrunner will make its debut in the second half of 2011 in two striking colour versions including Graphite Black / Matt Moonstone Silver Metallic and Candy Blazing Red / Matt Moonstone Silver Metallic.
2011 Honda Crossrunner - United States of America Specifications
USA MSRP - $TBA USD
ENGINE
Type Liquid-cooled 4-stroke 16-valve DOHC 90� V-4
Displacement 782cm3
Bore x Stroke 72 x 48mm
Compression Ratio 11.6 : 1
Max. Power Output 74.9kW/10,000min-1 (95/1/EC)
Max. Torque 72.8Nm/9,500min-1 (95/1/EC)
Idling Speed 1,200min-1
Oil Capacity 3.8 litres
FUEL SYSTEM
Carburation PGM-FI electronic fuel injection
Throttle Bore 36mm
Aircleaner Oil-permeated, cartridge-type paper filter
Fuel Tank Capacity 21.5 litres
ELECTRICAL SYSTEM
Ignition System Computer-controlled digital transistorised with electronic advance
Ignition Timing 8� BTDC (idle) ~ 50� BTDC (1,200min-1)
Sparkplug Type IMR9D-9H (NGK); VNH27Z (DENSO)
Starter Electric
Battery Capacity 12V/11AH (YTZ-12S)
ACG Output 386W
Headlights 12V; 55W x 1 (low) / 55W x 1 (high)
DRIVETRAIN
Clutch Wet, multi-plate with coil springs
Clutch Operation Hydraulic
Transmission Type Constant mesh 6-speed
Primary Reduction 1.934 (64/33)
Gear Ratios
1 2.846 (37/13)
2 2.062 (33/16)
3 1.578 (30/19)
4 1.291 (31/24)
5 1.111 (30/27)
6 0.965 (28/29)
Final Reduction 2.687 (43/16)
Final Drive O-ring sealed chain
FRAME
Type Diamond; aluminium twin-spar; pivotless
CHASSIS
Dimensions (L x W x H) 2,130 x 799 x 1,243mm
Wheelbase 1,464mm
Caster Angle 25� 45'
Trail 96mm
Turning Radius 2.8m
Seat Height 816mm
Ground Clearance 140mm
Kerb Weight 240.4kg (F: 115.2kg; R: 125.2kg)
SUSPENSION
Type Front: 43mm cartridge-type telescopic fork with stepless preload adjustment, 165mm axle travel
Rear: Pro-Link with gas-charged HMAS damper, 7-step preload and stepless rebound damping adjustment, 145mm axle travel
WHEELS
Type Front: 6-spoke cast aluminium
Rear: 5-spoke cast aluminium
Rim Size Front: 17M/C x MT3.50
Rear: 17M/C x MT5.50
Tyre Size Front: 120/70 R17
Rear: 180/55 R17
Tyre Pressure Front: 225kPa
Rear: 250kPa
BRAKES
Type Front: 296mm dual floating hydraulic disc with 3-piston calipers, C-ABC and sintered metal pads
Rear: 256mm hydraulic disc with 2-piston caliper, C-ABS and sintered metal pads
All specifications are provisional and subject to change without notice.
2011 Honda Crossrunner - Canadian Specifications
Canada MSRP - $TBA CDN
ENGINE
Type Liquid-cooled 4-stroke 16-valve DOHC 90� V-4
Displacement 782cm3
Bore x Stroke 72 x 48mm
Compression Ratio 11.6 : 1
Max. Power Output 74.9kW/10,000min-1 (95/1/EC)
Max. Torque 72.8Nm/9,500min-1 (95/1/EC)
Idling Speed 1,200min-1
Oil Capacity 3.8 litres
FUEL SYSTEM
Carburation PGM-FI electronic fuel injection
Throttle Bore 36mm
Aircleaner Oil-permeated, cartridge-type paper filter
Fuel Tank Capacity 21.5 litres
ELECTRICAL SYSTEM
Ignition System Computer-controlled digital transistorised with electronic advance
Ignition Timing 8� BTDC (idle) ~ 50� BTDC (1,200min-1)
Sparkplug Type IMR9D-9H (NGK); VNH27Z (DENSO)
Starter Electric
Battery Capacity 12V/11AH (YTZ-12S)
ACG Output 386W
Headlights 12V; 55W x 1 (low) / 55W x 1 (high)
DRIVETRAIN
Clutch Wet, multi-plate with coil springs
Clutch Operation Hydraulic
Transmission Type Constant mesh 6-speed
Primary Reduction 1.934 (64/33)
Gear Ratios
1 2.846 (37/13)
2 2.062 (33/16)
3 1.578 (30/19)
4 1.291 (31/24)
5 1.111 (30/27)
6 0.965 (28/29)
Final Reduction 2.687 (43/16)
Final Drive O-ring sealed chain
FRAME
Type Diamond; aluminium twin-spar; pivotless
CHASSIS
Dimensions (L x W x H) 2,130 x 799 x 1,243mm
Wheelbase 1,464mm
Caster Angle 25� 45'
Trail 96mm
Turning Radius 2.8m
Seat Height 816mm
Ground Clearance 140mm
Kerb Weight 240.4kg (F: 115.2kg; R: 125.2kg)
SUSPENSION
Type Front: 43mm cartridge-type telescopic fork with stepless preload adjustment, 165mm axle travel
Rear: Pro-Link with gas-charged HMAS damper, 7-step preload and stepless rebound damping adjustment, 145mm axle travel
WHEELS
Type Front: 6-spoke cast aluminium
Rear: 5-spoke cast aluminium
Rim Size Front: 17M/C x MT3.50
Rear: 17M/C x MT5.50
Tyre Size Front: 120/70 R17
Rear: 180/55 R17
Tyre Pressure Front: 225kPa
Rear: 250kPa
BRAKES
Type Front: 296mm dual floating hydraulic disc with 3-piston calipers, C-ABC and sintered metal pads
Rear: 256mm hydraulic disc with 2-piston caliper, C-ABS and sintered metal pads
All specifications are provisional and subject to change without notice.
2011 Honda Crossrunner Press Release
Honda's New Adventure Touring Bike Crosses The Divide
Debuting at EICMA in Milan this week, Honda's exciting new entry into the adventure touring category - the Crossrunner - represents the best of two biking genres: the flexibility of a performance machine with an upright riding position as well as the rugged appearance of an adventure bike.
The Crossrunner is powered by a liquid-cooled 782cc, 4 cam, V4 engine with VTEC that delivers a smooth curve of power with excellent torque throughout the rev range.
This provides the rider a precisely controlled experience, be it for short urban trips or for covering vast distances.
Thee rider's level of control is further enhanced by the wider than normal handlebar configuration, responding accurately yet quickly to small steering inputs, whilst its aluminium alloy twin-spar frame provides excellent rigidity.
The Crossrunner has also been designed to maximise pillion comfort. The passenger is seated on a level, low platform to make mounting and dismounting easier whilst maximising wind protection.
The bike's low-slung 4-2-1 exhaust system leaves room for a lower, flatter pillion seat as well as allowing for an attractive exhaust design, excellent cornering clearance and that distinctive V4 engine note.
Crucial machine data is provided by a 'floating' instrument binnacle, placed high for optimum visibility at all times, including a digital LCD speedometer, tachometer, twin trip meters, a coolant temperature gauge, an ambient temperature indicator and a clock.
A 43mm cartridge-type front fork provides supreme front wheel control and excellent rider feedback.
Cast aluminium Pro-Arm swingarm, Pro-Link rising-rate linkage system and gas-charged HMAS damper with adjustable rebound combine for comfort and precise control.
Braking is of the highest standard and includes high-performing Combined brakes with standard-fit ABS to create powerful, assured braking with optimised control and feedback.
The Crossrunner will make its debut in the second half of 2011 in two striking colour versions including Graphite Black / Matt Moonstone Silver Metallic and Candy Blazing Red / Matt Moonstone Silver Metallic.
